WI-TEK, WI-PS310GF-I-V2, Switch PoE Industrial No administrable / Puertos 1-2 PoE 802.3 af/at y PoE 24 Vcc Pasivo 30W / Puertos

Switch PoE Industrial No administrable / Puertos 1-2 PoE 802.3 af/at y PoE 24 Vcc Pasivo 30W / Puertos 3-4 PoE 802.3 af/at/bt H…

WI-TEK
193442
WI-TEK · WI-PS310GF-I-V2 · Switch PoE Industrial No administrable / Puertos 1-2 PoE 802.3 af/at y PoE 24 Vcc Pasivo 30W / Puertos 3-4 PoE 802.3 af/at…
Out of Stock
$304.07
IVA incluido
Cantidad

Últimas piezas!
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Switch PoE Industrial No administrable / Puertos 1-2 PoE 802.3 af/at y PoE 24 Vcc Pasivo 30W / Puertos 3-4 PoE 802.3 af/at/bt Hasta 60W / Puertos 5-8 PoE 802.3 af/at Hasta 30W / Los 8 puertos son Gigabit + 2 SFP combo / Presupuesto 300W

WI-PS310GF-I-V2

Modelo: WI-PS310GF-I-V2

Marca: WI-TEK

Especificaciones:

Switch PoE de largo alcance hasta 250 m

PoE de largo alcance con tecnología de extensión de red de patente exclusiva, utiliza el par trenzado existente común, puede soportar la transmisión de datos de hasta 250 metros, rompe el límite de transmisión de cien metros. Reduciendo su velocidad a 10 Mbps y un PoE máximo de 7 W.

Port VLAN

Ayuda a prevenir tormentas de broadcast

Función Smart PoE Watchdog en un Switch no Administrable

Plug and play, sin configuración. Detecta automáticamente y reinicia la cámara IP, esto si se pierde conectividad con la cámara.


Especificaciones
Dimensiones 200 x 140 x 50 mm
Interfaces
de Red
(8) 10/100/1000 Mbps
(2) SFP Gigabit Combo
(2) Uplink Gigabit Combo
Alimentación Con PoE:
V1 (principal): 37-57 Vcc
V2 (respaldo): 37:57 Vcc
Sin PoE:
V1 (principal): 12-36 Vcc
V2 (respaldo): 12-36 Vcc
Tipo de PoE 802.3 af/at: End-span
24V pasivo: Mid-span
802.3 af/at/bt: Mid-span y End-span
Consumo propio 30W
Puertos PoE(RJ45) Puertos: 1-2 PoE 24V pasivo / 802.3 af/at 30W
Puestos: 3-4 PoE 802.3 af/at/bt 60W
Puestos: 5-8 PoE 802.3 af/at 30W
Presupuesto de PoE: 300W
Bandwidth  20 Gbps
Mac Address Table 2K
Packet Forwarding Rate 14.88 Mpps
Montaje Pared / Riel DIN
Nivel de protección Lightning protection 6KV
6KV ESD Contact discharge
Temperatura de operación -40 to 80° C
Certificaciones CE, FCC
Características
Método de Transmisión Store-And-Forward
Funciones Avanzadas Priority Function
Mac Address Auto-Learning
IEEE802.3x flow control for Full-duplex mode
Backpressure for Half-duplex mode
Support VLAN
Otros
Contenido del Paquete Switch PoE
Kit de Montaje en Rack
Guía de Usuario/Garantía
