Comprar Lector Huella Suprema BLN2PAB | Smartgrid México

Lector de Huella IP67 Con Teclado y Lector de Tarjetas RFIDNFC y (125kHz EM, HID Prox &13.56Mhz MIFARE, MIFARE Plus, DESFire/EV…

Name: Lector de Huella IP67 Con Teclado y Lector de Tarjetas RFIDNFC y (125kHz EM, HID Prox &13.56Mhz MIFARE, MIFARE Plus, DESFire/EV…
Brand: SUPREMA
SKU: 171792
Price: 1234.76 USD
Availability: OutOfStock

Marca : SUPREMA

Referencia : 171792

Lector de huella Suprema BLN2PAB IP67 para exterior, 1.77” TFT, 10,000 usuarios, compatible con RFID/NFC. Ideal para control de acceso.

Out of Stock

$1,234.76

IVA incluido

Cantidad

Últimas piezas!

Add to Compare

Add to Wishlist

Security policy

(edit with the Customer Reassurance module)

Delivery policy

(edit with the Customer Reassurance module)

Return policy

(edit with the Customer Reassurance module)

Guarantee safe checkout

Información de Producto

Lector de Huella IP67 Con Teclado y Lector de Tarjetas RFIDNFC y (125kHz EM, HID Prox &13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR),NFC y BLUETOOTH, Certificado FBI PIV

Modelo: BLN2PAB

Marca: SUPREMA

Especificaciones:

BioLite N2 Bluetooth y NFC

Terminal de Huella IP67 Para exterior Control de Accesos y Asistencias

Suprema, uno de los principales líderes biométricos en seguridad tecnológica, presenta uno de los mejores algoritmos biométricos con una ingeniería superior. Se encuentra constantemente desarrollando y produciendo productos líderes en la industria, extendiendo su portafolio de productos de control de acceso y tiempo y asistencia en todo el mundo.

Características Físicas y Eléctricas:

Pantalla: 1.77” TFT LCD.
Comunicación: TCP/IP..
Interfaz RS-485 para comunicación o módulo esclavo SIO2.
Salida de relevador.
Wiegand: entrada y salida. (seleccionable)
Certificados: CE, FCC, KC, RoHS, REACH, WEE.
Alimentación: 12 Vcc, 1 A (fuente no incluida)
Dimensiones: 155 x 155 x 40 mm.

Usuarios:

Usuarios (1:1) 10,000.
Usuarios (1:N) 10,000.
Plantillas (huellas) (1:1) 20,000.
Plantillas (huellas) (1:N) 20,000.
Eventos: 1 000 000.

Notas :

BLN2OAB Con Teclado y Lector de Tarjetas RFIDNFC y (125kHz EM, HID Prox &13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, iCLASS SE/SR),NFC y BLUETOOTH.
Requiere de software BIOSTAR2 2.6 o superior (no incluido)

Visite nuestra Base de conocimiento de

SUPREMA

Specificationes

Scroll left/right

Model Name

Credential

RF Option
RF read range ²⁾
Mobile Card

Protections

IP rating
IK rating

Fingerprint

Template
Extractor / Matcher
Live Fingerprint Detection

Capacity

Max. User
Max. Credential (1:N)
Max. Credential (1:1)
Max. Text Log
Max. Image Log

General

CPU
Memory
Crypto Chip
LCD Type
LED
Sound
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Weight
Dimension (WxHxD, mm)
Certifications

Interface

Wi-Fi
Ethernet
RS-485
RS-485 Communication Protocol
Wiegand
TTL Input
Relay
USB
SD Card
PoE
Intercom
Tamper

Electrical

Power

BLN2-ODB

125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, NFC & 2.4GHz BLE

MIFARE/DESFire: 50 mm, EM/FeliCa: 30 mm

NFC, BLE

IP67

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Supported (SW-based)

10,000

Fingerprint: 10,000

Fingerprint: 10,000 / Card: 10,000 / PIN: 10,000

1,000,000

Not supported

1.2 GHz

4GB Flash + 64Mb RAM

Supported

1.77” color TFT LCD

Not supported

16-bit

-20°C ~ 50°C (-4°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 255g, Bracket: 57g (including washers and bolts)

58 x 190 x 44 (Bottom) / 34.6 (Top) (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, SIG, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1 ch Master / Slave (Selectable)

OSDP V2 Compliant

1 ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.4 A

BLN2-OAB

125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, iCLASS SE/SR/Seos, NFC & 2.4GHz BLE

MIFARE/DESFire: 50 mm, EM/FeliCa: 30 mm

NFC, BLE

IP67

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Supported (SW-based)

10,000

Fingerprint: 10,000

Fingerprint: 10,000 / Card: 10,000 / PIN: 10,000

1,000,000

Not supported

1.2 GHz

4GB Flash + 64Mb RAM

Supported

1.77” color TFT LCD

Not supported

16-bit

-20°C ~ 50°C (-4°F ~ 122°F)

-40°C ~ 70°C (-40°F ~ 158°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 255g, Bracket: 57g (including washers and bolts)

58 x 190 x 44 (Bottom) / 34.6 (Top) (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, SIG, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1 ch Master / Slave (Selectable)

OSDP V2 Compliant

1 ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.4 A

BLN2-PAB

125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3¹⁾, FeliCa, iCLASS SE/SR/Seos, NFC & 2.4GHz BLE

MIFARE/DESFire: 50 mm, EM/FeliCa: 30 mm

NFC, BLE

IP67

Not supported

SUPREMA / ISO 19794-2 / ANSI 378

MINEX certified and compliant

Supported (SW-based)

10,000

Fingerprint: 10,000

Fingerprint: 10,000 / Card: 10,000 / PIN: 10,000

1,000,000

Not supported

1.2 GHz

4GB Flash + 64Mb RAM

Supported

1.77” color TFT LCD

Not supported

16-bit

-10°C ~ 50°C (14°F ~ 122°F)

-20°C ~ 60°C (-4°F ~ 140°F)

0% ~ 80%, non-condensing

0% ~ 90%, non-condensing

Device: 255g, Bracket: 57g (including washers and bolts)

58 x 190 x 44 (Bottom) / 34.6 (Top) (mm)

CE, UKCA, KC, FCC, IC, RCM, BIS, SIG, RoHS, REACH, WEEE

Not supported

Supported (10/100 Mbps, auto MDI/MDI-X)

1 ch Master / Slave (Selectable)

OSDP V2 Compliant

1 ch Input / Output (Selectable)

2ch Inputs

1 Relay

Not supported

Supported

Voltage: 12 Vdc
Current: Max. 0.4 A

¹⁾DESFire EV2/EV3 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with BioLite N2.

²⁾RF read range will vary depending on installation environment.
