VIAKON, RG-8U-SYS/1000, Cable Coaxial / RG8 / 305 metros / 50 OHMS / 4.1 dB / Malla de Cobre al 97 % / Hecho en México / Intempe

Cable Coaxial / RG8 / 305 metros / 50 OHMS / 4.1 dB / Malla de Cobre al 97 % / Hecho en México / Intemperie

VIAKON
28051
VIAKON · RG-8U-SYS/1000 · Cable Coaxial / RG8 / 305 metros / 50 OHMS / 4.1 dB / Malla de Cobre al 97 % / Hecho en México / Intemperie
Hurry! only 9 items left in stock.
$1,555.13
IVA incluido
Cantidad

Últimas piezas!
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Cable Coaxial / RG8 / 305 metros / 50 OHMS / 4.1 dB / Malla de Cobre al 97 % / Hecho en México / Intemperie

RG-8U-SYS/1000

Modelo: RG-8U-SYS/1000

Marca: VIAKON

Especificaciones:



RG8-USYS/1000

Coaxial formado por un conductor flexible o sólido de cobre, aislamiento de polietileno espumado o polietileno semi-rígido, blindaje formado por una malla de cobre o cobre estañado y cubierta general de polocloruro de vinilo retardante a la flama ( FRPVC )



  El cable coaxial RG-8 se usa principalmente para conectar equipos de radio a sus antenas en aplicaciones donde se necesita baja pérdida de señal y resistencia en exteriores.



Características

  • CONDUCTOR
  • Numero de Conductores : 1
  • Material : Cobre
  • Calibre : 11 AWG
  • Diametro exterior : 0.109"
  • AISLAMIENTO
  • Aislamiento : Polietileno Espumado ( SFS )
  • Cobertura : 97 %
  • CUBIERTA
  • Material : PVC
  • Espesor Nominal : 0.045"
  • Diámetro Externo Nominal : 0.399"
  • Color : Negro

Certificaciones

  • UL 444 : Cables para Comunicaciones
  • UL 1655 : Televisión por cable de antena comunitaria
  • NEC Articulo 820 : Antena Comunitaria de TV y Sistemas de distribución de radio
  • NMX-I-118/02-NYCE-2008 : Cable Coaxial para Acometida en sistemas de Televisión por cable (STVC)

Modelos relacionados :

  • RG8-USYS/25M
  • RG8-USYS/30M
  • RG8-USYS/50M
  • RG8-USYS/100M
