Kit / Fuente PLK12DC4ABK + Batería incluída LK712
Kit / Fuente PLK12DC4ABK + Batería incluída LK712
Modelo: PLK12DC4ABK/K
Marca: EPCOM POWERLINE
Especificaciones:
PLK12DC4ABK/K
Fuente de alimentación 11- 15 Vcc @ 4 Amper
Incluye batería de respaldo de 12 Vcc @ 7 Ah LK712
Sistemas de alimentación para aplicaciones en sistemas de seguridad electrónica y comunicación.
Características de la Fuente :
- Voltaje de entrada: 96-264 Vca
- Voltaje de salida : 11- 15 Vcc
- Corriente de salida : 4 Amper
- Frecuencia nominal : 50-60 Hz
- Salida temporizada de : 0 a 45 segundos
- Dimensiones ( mm ) : 214.5 x 200 x 71
- Peso : 1.94 Kgs.
Características de la Batería :
- Capacidad en Ah: 7.
- Tipo de terminal : F1
- Voltaje (Vcc): 12.
- Tipo: AGM/VRLA.
- Dimensiones (mm): 65 x 101 x 151
- Peso (kg): 2.05
Productos relacionados :
- PL-12DC-3A-BK/K
- PL-12DC-5A-BK/K
- PS-12DC-4P-BK/K
- PLK-12DC-8A-BK/K
- PLK-12DC-20A-BK/K
