Balun E1 - Adaptador 75 ohms a jack RJ45 120 ohms tipo pigtail
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
(edit with the Customer Reassurance module)
Modelo: BALUN-E1-P
Marca: EPCOM
La función de un balun E1 generalmente es convertir una señal portadora E1 de un cable coaxial a un cable UTP.
Características
Especificaciones
Velocidad de datos 2048 Kbps
Interface desbalanceada 75 ohm impedancia, 2 x BNC
Interface balanceada 120 ohm impedancia, 1 x RJ45
Perdida de inserción 0.2dB (2 Mbps)
Perdida de retorno -29dB (2 Mbps)
Dimensiones 54 x 44 x 25 mm
Peso 45g
Compliance ITU G.703 standard pulse
Temperatura de operación 0 ~ 75°C
Aplicación
