Comprar Transistor TPL B2-224 70W | Smartgrid México

Silicon RF Power MOSFET Power Transistor, 175 MHz, 530 MHz, 70W

TPL COMMUNICATIONS
69355
Transistor TPL B2-224 Silicon RF Power MOSFET de 70W, 175 MHz a 530 MHz. Ideal para aplicaciones de radiocomunicación. Mejora tu conectividad.
Out of Stock
$102.45
IVA incluido
Cantidad

Últimas piezas!
Add to Compare
Add to Wishlist
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Silicon RF Power MOSFET Power Transistor, 175 MHz, 530 MHz, 70W

B2-224

Modelo: B2-224

Marca: TPL COMMUNICATIONS

Especificaciones:


DESCRIPTION
RD70HUF2 is MOS FET type transistor specifically designed for VHF/UHF RF power amplifiers applications.

FEATURES
1. Supply with Tape and Reel. 500 Units per Reel 2. Employing Mold Package
3. High Power and High Efficiency
Pout=75Wtyp, Drain Effi.=64%typ
@ Vds=12.5V Idq=1.0A Pin=5.5W   f=530MHz
Pout=84Wtyp, Drain Effi.=74%typ
@ Vds=12.5V Idq=1.0A Pin=4.0W  f=175MHz
4. Integrated gate protection diode

APPLICATION
For output stage of high power amplifiers in VHF/UHF band mobile radio sets.

RoHS COMPLIANT
RD70HUF2 is a RoHS compliant product. RoHS compliance is indicating by the letter “G” after the Lot Marking. This product includes the lead in high melting temperature type solders.
However, it is applicable to the following exceptions of RoHS Directions.
1. Lead in high melting temperature type solders. (i.e. tin-lead solder alloys containing more than85% lead.)

: 69355
