Comprar Type N Male OnePiece™ L5PNM-RPC | Smartgrid México

Type N Male OnePiece™ for 7/8 in LDF5-50A cable

ANDREW
21214
Conector Type N Male OnePiece™ L5PNM-RPC para cable LDF5-50A. Diseñado para radiocomunicación, garantiza conexión confiable y duradera.
Out of Stock
$48.50
IVA incluido
Cantidad

Últimas piezas!
Add to Compare
Add to Wishlist
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Type N Male OnePiece™ for 7/8 in LDF5-50A cable

L5PNM-RPC

Modelo: L5PNM-RPC

Marca: ANDREW

Especificaciones:

ELECTRICAL SPECIFICATIONS

AVERAGE POWER

0.6 kW @ 900 MHz

CABLE IMPEDANCE

50 ohm

DC TEST VOLTAGE

2000 V

CONNECTOR IMPEDANCE

50 ohm

PEAK POWER, MAXIMUM

10.00 kW

3RD ORDER IMD, TYPICAL

-120 dBm @ 910 MHz

INSERTION LOSS, TYPICAL

0.05 dB

SHIELDING EFFECTIVENESS

-130 dB

OPERATING FREQUENCY BAND

0 – 5000 MHz

3RD ORDER IMD TEST METHOD

Two +43 dBm carriers

INSULATION RESISTANCE, MINIMUM

5000 MOhm

INNER CONTACT RESISTANCE, MAXIMUM

2.00 mOhm

OUTER CONTACT RESISTANCE, MAXIMUM

0.30 mOhm

RF OPERATING VOLTAGE, MAXIMUM (VRMS)

707.00 V
: 21214
