Comprar Antena Marina VHF 8 dB 150W | Smartgrid México

Antena Marina Phase III VHF, 8 dB, 150 Watts.

SHAKESPEARE
195558
Antena Marina Phase III VHF 8 dB, 150 Watts con elementos de cable de cobre. Dimensiones de 294.64 x 9.22 cm, ideal para comunicación profesional.
Out of Stock
$1,321.17
IVA incluido
Cantidad

Últimas piezas!
Add to Compare
Add to Wishlist
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Antena Marina Phase III VHF, 8 dB, 150 Watts.

6018-R

Modelo: 6018-R

Marca: SHAKESPEARE

Especificaciones:




6018-R Phase III VHF Antena



Características:

  • Elementos de cable de cobre de calidad para un buen alcance y eficiencia.
  • Conductor exterior plateado, he interno de cobre
  • Mango de montaje en acero.
  • Conector S0-239 (PL) hembra
  • Dos secciones.
  • Montaje sugerido: montaje 4187 o 410R  (se vende por separado)




6018-R Specifications

Diseño:

Elementos colineales de 1/2 onda en fase

Altura:

18’ (5.48m)

Peso:

20lbs (9kg)

Ganancia:

8dB

Tipo de conector:

SO-239

Montaje sugerido:

409-R o 410-R

Boat Length:

≥22′ (≥6.7m)

UPS Shippable:

No

SWR:

<1.5:1 at 156.8 MHz

Ancho de banda:

3 MHz dentro de 2.0:1 VSWR

Impedancia:

50 ohms

Potencia maxima:

150w

Conexión a tierra.

No

Dimensiones: 294.64 x 9.22 x 9.22 cm (dos secciones)

Peso aprox. en empaque : 9 kg
