PYTES, BUSBAR300A, Bloque de Terminales de 12+2 Líneas, 300A, para Baterias

Bloque de Terminales de 12+2 Líneas, 300A, para Baterias

PYTES
230778
PYTES · BUSBAR300A · Bloque de Terminales de 12+2 Líneas, 300A, para Baterias
Out of Stock
$91.40
IVA incluido
Cantidad

Últimas piezas!
Add to Compare
Add to Wishlist
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Bloque de Terminales de 12+2 Líneas, 300A, para Baterias

BUSBAR300A

Modelo: BUSBAR300A

Marca: PYTES

Especificaciones:

Especificaciones Tecnicas

Busbar 300 A with cover

Maxima Corriente:

300 A

Maxima voltaje

52 VDC or 300 VAC

Diemetro de la terminal:

M8/8mm

Altura de terminaes

30mm

Material de la terminal

Acero inoxidable

Material de la tuerca

Acero inoxidable

Torqie Recomendado

7 N·m

Terminales de tornillo

M6/6mm

Material de Terminales

Acero Inoxidable

Material de la tira de barras

Cobre estañado (8 x 25 mm)

Base del Material

ABS, black

Material de la cubierta

Policarbonato trasparente

Peso

0.48kg

dimensiones.
(hxwxd) (with cover):

200 x 34 x 59 mm

: 230778
