Comprar Type N Male F4PNMV2 50 Ohm | Smartgrid México

Type N Male for 1/2 in FSJ4-50B cable

ANDREW / COMMSCOPE
79409
Conector N Male F4PNMV2 de ANDREW para cable FSJ4-50B. Impedancia de 50 ohm, frecuencia de 0-12000 MHz. Ideal para radiocomunicación.
Out of Stock
$59.69
IVA incluido
Cantidad

Últimas piezas!
Add to Compare
Add to Wishlist
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Type N Male for 1/2 in FSJ4-50B cable

F4PNMV2

Modelo: F4PNMV2

Marca: ANDREW / COMMSCOPE

Especificaciones:

General Specifications
  • Interface: N Male
  • Body Style: Straight
  • Brand: HELIAX®
  • Mounting Angle: Straight
Electrical Specifications
  • Connector Impedance: 50 ohm
  • Operating Frequency Band: 0 – 12000 MHz
  • Cable Impedance: 50 ohm
  • 3rd Order IMD, typical: -120 dBm @ 910 MHz
  • 3rd Order IMD Test Method: Two +43 dBm carriers
  • RF Operating Voltage, maximum (vrms): 707.00 V
  • dc Test Voltage: 2000 V
  • Outer Contact Resistance, maximum: 0.30 mOhm
  • Inner Contact Resistance, maximum: 2.00 mOhm
  • Insulation Resistance, minimum: 5000 MOhm
  • Average Power: 0.6 kW @ 900 MHz
  • Peak Power, maximum: 10.00 kW
  • Insertion Loss, typical: 0.05 dB
  • Shielding Effectiveness: -110 dB
Dimensions
  • Nominal Size: 1/2 in
  • Diameter: 23.62 mm   |   0.93 in
  • Length: 50.80 mm   |   2.00 in
  • Weight: 163.00 g   |   0.36 lb
: 79409
