WAGO
226740
Out of Stock
$1,517.54
Tax included
Quantity

Last items in stock
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Información de Producto

Smart printer wago

258-5000

Modelo: 258-5000

Marca: WAGO

Especificaciones:

Método de marcajeTermotransferencia
Cabezal de impresiónGlass layer, spring-mounted
Resolución de impresión300
Resolución de impresión300 dpi (12 pixels/mm)
Velocidad de impresión (máx.)max. 127 mm/s (WAGO recommends 50.8 mm/s)
Recommended print speed50
Print speed (max.)127
Anchura de impresión47mm
Longitud de impresión (max.)762mm
Sensor de reflexión de luzyes, centrally fixed
Memoria8MB
Marking softwareSmart Script
InterfacesUSB, RS-232, ETHERNET 10/100Mbps
Tensión de funcionamiento100 … 240 VAC, 50 … 60 Hz (automatic adjustment)
Certificados de seguridadCE (EMC)
Panel de operadorColor TFT LCD with navigation button
Cinta de tintaReel outside diameter: 40 mm; core inside diameter 12.7 mm (0.5 inch); max. length 110 m; max. width 58 mm
Cinta de tinta (anchura)50 mm / 1.969 pulgadas
Cinta de tinta (longitud)74 m / 360.9
Diámetro externo de rollo de cinta de tinta33 mm / 1.299 pulgadas
Diámetro interno de núcleo de cinta de tinta12.5 mm / 0.492 pulgadas
Volumen de entregaFuente de alimentación + cable, 2 x rodillo (258‑5006 + 258‑5007), 1 x soporte de rojo, 1 x tira de tinta (258-5005), software de marcaje Smart Script y controlador, cable USB, desbobinador externo, 2 núcleos de rollo de cartón vacíos; 1 x rollo de tiras de marcadores (2009-110) y etiquetas de inserción WMB Inline (2009-115)
: 226740
Out of Stock
