BioEntry W2 Lector de Huella para Exterior IP67 / IK09 / Certificado UL /Multiformato (Lector 125 KHz EM / HID Prox 13.56MHz, MIFARE / NFC / DESFire(EV1) / FeliCa / iClass SE)
Modelo: BEW2OAPUL
Marca: SUPREMA
Especificaciones:
BioEntry W2 Lector de Huella de Exterior IP67/ IK09/ MULTIFORMATO
Certificado UL
Lector Biométrico para Exterior Más Avanzado del Mundo
Suprema, uno de los principales lideres biométricos en seguridad tecnológica, presenta uno de los mejores algoritmos biométricos con una ingeniería superior. Se encuentra constantemente desarrollando y produciendo productos líderes en la industria, extendiendo su portafolio de productos de control de acceso y tiempo y asistenciaen todo el mundo.
Caracteristicas
- Grado de Protección IP67.
- Proteccion de impacto IK09
- Detección de dedo vivo.
- Comunicación: TCP/IP.
- Interfaz RS-485 para comunicación o módulo esclavo SIO2.
- Salida de relevador.
- Wiegand: entrada y salida (seleccionable).
- Certificados: CE, FCC, KC, RoHS, REACH, WEE.
- Dimensiones: 50 x 172 x 43.5 mm
- BEW2OAP con Lector 125KHz EM/HID Prox 13.56 MHZ, MIFARE®/ NFC /DESFire(EV1)/ FeliCa/iClass® SE, Compatible con tarjeta SEOS8KC26 y SEOS8KC (tecnología no clonable)
Usuarios:
- Usuarios (1:1) 500,000.
- Usuarios (1:N) 100,000.
- Plantillas (huellas)(1:1) 1,000,000.
- Plantillas (huellas) (1:N) 200,000.
- Eventos 1 000 000.
Notas:
- Alimentación: 12 Vcc, 1 A y PoE. Fuente no incluida.
- Requiere de software BIOSTAR2.
- Utilizar PoE, solo si el equipo es utilizado para asistencia, En caso de conectar cerradura o cualquier otro dispositivo de apertura, debe ser alimentado con fuente.
- Para operacion de NFC (pregunte por compatibilidad de equipos)
Visite nuestra Base de conocimiento de SUPREMA
