Información de Producto

Radio de Backhaul de alta capacidad, tecnología airFiber hasta 1 Gbps, 60 GHz con failover en 5 GHz, con antena integrada de 38 dBi y 11 dBi respectivamente

AF60

Modelo: AF60

Marca: UBIQUITI

Especificaciones:



Especificaciones técnicas
Dimensiones 413 x 413 x 320 mm
(16.26 x 16.26 x 12.60")
Peso
Sin el montaje
Con el montaje
1.4 kg (3.09 lb)
1.8 kg (3.97 lb)
Enclosure Aluminum, UV-stabilized Polycarbonate
Ganancia Antena
5 GHz
60 GHz
11 dBi
38 dBi
Interfaz de red (1) 10/100/1000 Mbps
Consumo Máx. 11W
Metodo de alimentación PoE Pasivo, Pines 4, 5+ y 7, 8-
Fuente de alimentación 24VDC, 0.5A Adaptador PoE Gigabit (Incluido)
Rango de voltaje +22 to +26VDC
LEDs Power/Ethernet/5G/60G/GPS
Montaje Montaje en poste (Incluido)
Carga de viento 420 N @ 200 km/h
(94.4 lbf @ 125 mph)
Supervivencia del viento 200 km/h
(125 mph)
Protección ESD/EMP ± 24kV Contact/Air
Temperatura -40 to 60° C
(-40 to 140° F)
Humedad 5 to 95% Noncondensing
Certificaciones FCC, IC, CE
Sistema
Capacidad 1.8 Gbps
Rango Máximo 2+ km
Encriptación WPA2-PSK (AES)/WPA2 Enterprise
OS airOS GP
Radio
Max. Conducted TX Power
5/60 GHz Combined
25 dBm
Ancho de canal
60 GHz
5 GHz
2160 MHz
20/40/80 MHz
Frecuencias de operación (MHz)
US/CA
U-NII-1
U-NII-3
5150 – 5250
5725 – 5850
57,000 – 66,000
Worldwide 5180 - 5875
57,000 - 66,000
Radio de Administración (MHz)
Worldwide 2412 - 2472
US/CA 2412 - 2462
