Información de Producto

Radio airMAX LR de alta capacidad, hasta 1 Gbps en 60 GHz con failover en 5 GHz, con antena integrada de 38 y 11 dBi respectivamente

GBE-LR

Modelo: GBE-LR

Marca: UBIQUITI

Especificaciones:

Especificaciones técnicas
Dimensiones 415 x 415 x 303 mm
(16.34 x 16.34 x 11.93")
Peso
Sin montaje
Con montaje
1.4 kg (3.09 lb)
1.8 kg (3.97 lb)
Enclosure Aluminio, Policarbonato con resistencia UV
Ganancia Antena
5 GHz
60 GHz
11 dBi
38 dBi
Interfaz de Red (1) 10/100/1000 Mbps Ethernet Port
Consumo Máx. 11W
Metodo de alimentación PoE Pasivo, Pines 4, 5+ y 7, 8-
Fuente de alimentación 24VDC, 0.5A Adaptador PoE Gigabit (Incluido)
Rango de Voltaje +22 to +26VDC
LEDs Power/Ethernet/5G/60G
Carga de Viento 56 N @ 200 km/h
<(12.6 lbf @ 125 mph)
Wind Survivability 200 km/h
(125 mph)
Montaje Montaje en poste (kit incluido)
ESD/EMP Protection ± 24kV Contact/Air
Temperatura -40 to 60° C (-40 to 140° F)
Humedad 5 to 95% sin condensación
Certificaciones FCC, IC, CE
Radio
Max. Conducted TX Power
5/60 GHz Combined
25 dBm
Ancho de canal
60 GHz
5 GHz
2160 MHz
20/40/80 MHz
Frecuencias de operación (MHz)
US/CA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3
5150 - 5250
5250 - 5350
5470 - 5725
5725 - 5850
57,000 – 66,000
Worldwide 5180 – 5875
57,000 - 66,000
Radio de Administración (MHz)
Worldwide 2412 - 2472
US/CA 2412 - 2462
