Información de Producto

Antena Tipo Horn de 45 °, 15 dBi, 4.9 - 7GHz, Ideal para ambientes de alto ruido, Tipo de conector RPSMA, con montaje y jumpers incluidos

TXP-H15-MIMO

Modelo: TXP-H15-MIMO

Marca: TXPRO

Especificaciones:

Especificaciones Técnicas



  • Rango de frecuencia 4.9 a 7 GHz
  • Ganancia 15 dBi
  • VSWR <2.0
  • Polarización doble (V/H ± 45°)
  • Aislamiento >30 dB
  • Front ot back Ratio >30 dB
  • Ancho de haz horizontal 45°
  • Ancho de haz vertical 45°
  • Potencia máxima por puerto 50W
  • Impedancia 50 Ω
  • INCLUYE JUMPERS de RPSMA a RPSMA

Especificación Mecánicas

  • Conector RPSMA
  • Tamaño de la antena 150 x 140 mm
  • Peso 1 kg
  • Temperatura de operación -40, +70 °C (-32 °F to +158 °F)
  • Tornillos, turcas y montaje de acero inoxidable.
